Grade 3, ANSI standard A156.2
Trim and levers are zinc plated
Tubular body, Exposed screws, Easy installation
Kwikset 5-pin keyway. Rekeyable for master and construction keying
For wood and metal doors. Fits 1 3/8" to 1 3/4" thick doors
Atlas, Phoenix and Vanity designs have auto release for immediate egress on privacy functions
2 3/8" or 2 3/4" adjustable backset, size 1" x 2 1/4" round corner standard. Square corner option and drive-in latchbolt also available on special factory order.
Round Corner Full Lip Strike: 1 3/4" x 2 1/4", Optional T-strike
Keyed entry comes with lever/lever for exterior and interior
1" bore diameter for latch, 2 1/8" diameter for lock housing
